- Available for better dyeing performance.
- Possible to exactly control the feeding speed of fabric.
- Various application.
|
|
 |
| |
| Model |
Unit |
PYD-UJ1 |
PYD-UJ2 |
PYD-UJ3 |
| Max.W.Temperature |
ˇÉ |
|
140 |
|
| Max.W.Pressure |
kg/§˛ˇ¤g |
|
4.0 |
|
| Liquor Capacity |
Lit |
700~1,200 |
1,400~2,400 |
2,100~3,600 |
| Fabric Capacity |
kg |
140 |
280 |
420 |
| Total Elec.Power |
kw/hr |
17~18 |
33~34 |
50~52 |
| Heating(p:5~7kg/§˛ steam) |
min |
20 |
20 |
20 |
| Cooling(20ˇÉˇ¤2kg/§˛Cooling Water) |
min |
15 |
15 |
15 |
| Max.Fabric Speed |
m/min |
300~500 |
300~500 |
300~500 |
|
|
|
|
